0.33HP 1PH 48Z 4P DP 1725 SpP 115V

Description

Product Information

Brand Leeson
Mfr # H164
Wright’s # LSN H164
Country of Origin MEX

Specifications

C Dim 9.32″
Electrical Type Split Phase
Enclosure DP
Frame 48Z
Frequency 60 Hz
HP 0.33 HP
HP2 1/3 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 1
Rated Current 6.2
Rated Voltage 115
Rotation Counterclockwise/Clockwise
RPM 1725
Service Factor 1.35
Shaft Diameter 0.5″
Speed 1725
Starting Method
