0.25HP 1PH 48Z 4P DP 1725 SpP 115V AOL

Description

Product Information

Brand Leeson
Mfr # S126
Wright’s # LSN S126
Country of Origin MEX

Specifications

C Dim 9.72″
Electrical Type Split Phase
Enclosure DP
Full Load Efficiency 52.5
Frame 48Z
Frequency 60 Hz
HP 0.25 HP
HP2 1/4 HP
Insulation Class B
kW 0.19kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 5.3
Rated Voltage 115
Rotation Selective Counterclockwise
RPM 1725
Service Factor 1
Shaft Diameter 0.5″
Speed 1725
Starting Method
