0.25HP 1PH 48Y 6P TEAO 1075 PSC 208-230V AOL CF

Description

Product Information

Brand Leeson
Mfr # X412
Wright’s # LSN X412
Country of Origin MEX

Specifications

C Dim 10.75″
Electrical Type Permanent Split Capacitor
Enclosure TEAO
Full Load Efficiency 68.5
Frame 48Y
Frequency 60 Hz
HP 0.25 HP
HP2 1/4 HP
Insulation Class B
kW 0.19kW
Material Rolled Steel
MaAmbient 60°C
Mounting Type Round – Extended Studs
Number of Poles 6
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 1.4
Rated Voltage 208-230
Rotation Selective Counterclockwise
RPM 1075
Service Factor 1
Shaft Diameter 0.5″
Speed 1075
Starting Method
