0.25HP 1PH 48Y 4P OAO 1625 PSC 460V AOL CF

Description

Product Information

Brand Leeson
Mfr # X420
Wright’s # LSN X420
Country of Origin MEX

Specifications

C Dim 10.94″
Electrical Type Permanent Split Capacitor
Enclosure OAO
Full Load Efficiency 58
Frame 48Y
Frequency 60 Hz
HP 0.25 HP
HP2 1/4 HP
Insulation Class B
kW 0.19kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Round – Extended Studs
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 1.0
Rated Voltage 460
Rotation Selective Counterclockwise
RPM 1625
Service Factor 1
Shaft Diameter 0.5″
Speed 1625
Starting Method
