0.17HP 1PH 48Y 4P DP 1725 SpP 115V AOL

Description

Product Information

Brand Leeson
Mfr # B322
Wright’s # LSN B322
Country of Origin MEX

Specifications

C Dim 9.32″
Electrical Type Split Phase
Enclosure DP
Full Load Efficiency 55
Frame 48Y
Frequency 60 Hz
HP 0.17 HP
HP2 1/6 HP
Insulation Class B
kW 0.13kW
Material Rolled Steel
MaAmbient 40°C
Mounting Type Resilient Base – Extended Studs
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 3.6
Rated Voltage 115
Rotation Selective Counterclockwise
RPM 1725
Service Factor 1.35
Shaft Diameter 0.5″
Speed 1725
Starting Method
